Quick Details

  • Place of Origin: China (Mainland)
  • Brand Name: AVP
  • Model Number: AVP-001
  • Type: Cat 5e
  • Number of Conductors: 8
  • Conductor Material: BU/CCA/CCS/CCAG
  • Conductor OD: 0.51mm, 24awg
  • Insulation: PE
  • Twisted type: 4pair solid copper twisted
  • Jacket material: PVC/LSZH/CMP/ROHS
  • Cable diameter: 5.4mm
  • Jacket color: 12 colors available
  • Impedance: 200-500mhz
  • Working temperature: -40~+75
  • Data transmission distance: 1-200m

Packaging & Delivery

Packaging Details 1)Packing Lengths: 100m/roll, 200m/roll, 305m/roll, 100yard/roll, 200yard/roll, 300yard/roll Other lengths available according to client's request;
2) Inner packing: Wooden reel, plastic reel, and paper reel available.
3) Outer packing: Carton box, pull out box, pallet available.
4) Other packing available according to client's request
Delivery Time 7-10days

Hot Sales Cat5e cat6 cable Bare copper CCA CCS Pass CE and ROHS



CAT5e CABLE



ITEM

Description

Conductor

material

Bare copper

Construction

24AWG(1/0.50)

O.D.

0.5 mm±0.02mm



Insulation

Material

HD-PE

Thickness

0.269MM±0.05mm

O.D.

0.975MM±0.03mm

Elongation

Min.300%

tensile

Min.1.22kg/mm

Twist Pair

N/A

color

function

1. BlueWhite / Blue

Unused  Unused

2. OrangeWhite / Orange

Transmit Data +

Transmit Data -

3. GreenWhite / Green

Receive Data +

Receive Data -

4. Brown   White / Brown

Unused  Unused

Remark :  Network cabling comprises of four pairs of wires, only two pairs are normally used. Despite this, all the pairs should always be wired to maintain the network specification. The cable pair colors, pair numbers and wire descriptions are shown in the table



jacket



Material

PVC

Thickness

0.615mm±0.1mm

O. D .

5.2mm±0.3mm

Color

According to customer’s requirement

Elongation

Min.125%

tensile

Min.1.41kg/mm

weight

8.7kgs/305m











package

packing

1000FT/305M per box or as customer’s requirement

Package

Easy pull out box /wooden drum or as customer’s requirement

Boxes size

Ineer box

Outer box(two ineer box in one outer box)

34.5*34.5*19.5CM

41*35.8*36CM



Application

100 Base-TX, 100 Base-T4, 100VG-AnyLAN, 1000Base-T, ATM
