Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: AVP/IBMACS
  • Model Number: AVP-000
  • Type: Cat 6
  • Number of Conductors: 8
  • Condctor Material: BU/CCA/CCS/CCAG
  • Condctor OD: 0.51mm or 24awg
  • Jacket material: PVC, PE, CMP, LSZH
  • Cable OD: 05.4mm
  • Working temperature: -40~+70
  • Impedance: 200-500mhz
  • Packing: 1000ft/roll, 2rolls/carton
  • Jacket Color: black,white or as per client requ...
  • Product name: Cat7 lan cable
  • Brand: AVP/OEM/IBMACS

Packaging & Delivery

Packaging Details Box packing or per customer requirement
Delivery Time 7-10days

High speed Cat6 4 pair network Lan Cable with good quality



AVP Cat6 Network Cable Specification:

  1. AWG23 Solid Copper
  2. Single or Duplex,Dual shielded,
  3. PVC, PE or LSZH PVC
  4. ROHS/CE/ISO9001:2



Professional Telecom Grade Cat6 S/FTP LAN CABLE



1. Application:

     VoIP/ISDN/Token/100M TP-PDM/Analog and Data Video/TR-16 Active and Passive/155M,622M,1.2GATM/IEEE802.3;10Base-T;100Base-T;1000Base-T;10GBase-T

2. Cat6 LAN Cable Description:

    -Rated temperature:60°C,75°C,90°C

    -Reference Standard: UL444,UL1581

    -Solid bare copper conductor

    -PVC/LSZH Jacket, RoHS/REACH Compliant

    -Compliant to IEC61156-5,EN50173 & ISO11801

    -Operating Temperature:-30~+50°C

     -Minimum bending radius:8D



3.  Cat6 LAN Cable Mechanical Properties

-Conductor insulation material: halogen free Foam/Skin material

-Cable jacket material: halogen-free, flame-retardant material

-Application area: dray as well as humid rooms

-Temperature (moved): 0°C to 50°C

-Operating temperature: -20°C to +60°C

-Min. bending radius for one-time bending: 4×O.D.

-Min. bending radius during installation: 8×O.D.



4.  CAT6 LAN Cable  Electrical properties

-Loop impendence: 130 W/km

-Highest impendence difference: 2%

-Insulation resistance >5000 MW x km

-Impendence Z0 at 1 500MHz: 100 W ± 15%

-Impendence Z0 at 1 350MHz: 100 W ± 18%

-Impendence Z0 at 1 600MHz: 100 W ± 25%

-Surface transfer impendence: < 100 MW per Meter at 10MHz

-Earthing symmetry db/BZL = 1000m > 46dB at 64kHz

-Earthing symmetry db/BZL = 100m > 40dB at 1MHz

-Earthing symmetry db/BZL = 100m > 20dB at 100MHz

-Mutual capacitance: 43pF/m

-Highest earthing-coupling: 0,001MHz: 1000 pF/km

-Propagation speed at > 10MHz (NVP*c): 0,79c

-Signal propagation delay >10MHz: 4,2ns/m

-Skew: <25ns/100m



 5.  Transmission Properties: ( at 20°C)



Frequency [MHz]

1

10

16

20

31.25

62.5

100

300

600

Typical values (attenuation) [db/100m]

1.8

5.2

6.8

7.7

9.6

13.8

17.5

31.5

45.0

Typical values (NEXT) [db/100m]

>100

>100

>100

>100

>100

>100

98.0

93.0

89.0

Typical values (PSNEXT) [db/100m]

98.0

98.0

98.0

98.0

98.0

98.0

96.0

91.0

87.0

Typical values (ELFEXT) [db/100m]

93.0

93.0

93.0

93.0

90.0

86.0

84.0

65.0

45.0

Typical values (PSELFEXT) [db/100m]

91.0

91.0

91.0

91.0

88.0

84.0

82.0

63.0

43.0

Typical values (RL) [db/100m]

26.2

34.7

36.3

35.7

36.3

36.1

36.1

31.7

27.5

Typical values (ACR) [db/100m]

98.2

94.8

93.2

92.3

90.4

86.2

80.5

61.5

44.0
